Mil STD 810H Rain (Method 506.6) Test Room.

MIL-STD-810HIEC 60529

Walk-in environmental chamber configured for MIL-STD-810H Method 506.6 rain testing. The chamber accommodates large or vehicle-class equipment within a controlled enclosure designed to deliver the procedure-specific droplet size distribution, spray rate, and wind-driven rain conditions defined by the method. Internal dimensions, spray-head layout, and platform support are tailored to the equipment under test; configuration is finalized at the quotation stage based on the procuring activity’s MIL-STD-810H Annex F tailoring.

Applicable StandardMIL-STD-810G/H Method 506.6

Test ProceduresI (Blowing Rain), II (Exaggerated), III (Drip) — single or combined

ConstructionAISI 304 Stainless Steel, 1.5 mm

AccessWalk-in / drive-in

Control SystemPLC + HMI Touch Panel

Measured ParametersPressure (bar), Flow (m³/h), Temperature (°C)

Request quote →Talk to an engineer

/ 01

Standards
& methods.

Walk-In Chambers

StandardReference

MIL-STD-810HEnvironmental Engineering Considerations and Laboratory Tests

IEC 60529Degrees of Protection Provided by Enclosures (IP Code)

Beyond the catalogue

ULMEKA engineers test systems
to specification.

If your requirement is outside this catalogue — custom chamber sizes, combined-standard integration, or tailored test profiles — talk to our engineering team.
